2-588 MACHINE OPERATIONS OPERACIONES DE MECANIZADO
(Q41056 005)
No.
N°
Symbol
Símbolo
Drawing No
N° de Ilustra-
ción
Name
Designación
Model
Modelo
Q'ty
Ctd.
Maker
Fabricante
1 * * STOP VALVE STOP VALVE 3/8 1 CKD
2 * * AIR FILTER F3000-10-F8 1 CKD
3 SP3 * PRESSURE SWITCH APS-60-FL346462 1 CKD
4 YV1091 U40624A SOLENOID VALVE GFAB41-X1156-DC24V 1 CKD
5* *
PRESSURE REDUCING
VALVE
RA800-8-PGB 1 CKD
6 * U41449A AIR CYLINDER SCM-OO-63B-118-T0V3-D 1 CKD
7 * U40089A SPEED CONTROLLER SC3W-8-8 2 CKD
8
YV1030,
YV1031
* SOLENOID VALVE 4GB240-08-B-3 1 CKD
9* *
METERLIN VALVE WITH
SILENCER
2MW2-8A 2 CKD
10 YV1181 * SOLENOID VALVE FAB41-X0513-DC24V 1 CKD
11 * *
PRESSURE REDUCING
VALVE
RA800-8-LG 1 CKD
12 YV1241 * SOLENOID VALVE FAB41-X0513-DC24V 1 CKD
13 * * SPEED CONTROLLER SC3G-8-10 1 CKD
14 * *
PRESSURE REDUCING
VALVE
RA800-8-PGB 1 CKD
15 SP11 * PRESSURE SWITCH PPD-A-P10PKP-H-FL 1 CKD
16 * U40089A SPEED CONTROLLER SC3W-8-8 2 CKD
17 * U41449A AIR CYLINDER SCM-OO-63B-118-T0V3-D 1 CKD
18
YV1030,
YV1031
* SOLENOID VALVE 4GB240-08-B-3 1 CKD
19 * *
METERLIN VALVE WITH
SILENCER
2MW2-8A 2 CKD
20 YV2301 U40624A SOLENOID VALVE GFAB41-X0651-DC24V 1 CKD
21 YV1061 U40624A SOLENOID VALVE GFAB41-X0651-DC24V 1 CKD
22 YV2701 U40624A SOLENOID VALVE GFAB41-X0651-DC24V 1 CKD
23 YV1201 U40624A SOLENOID VALVE GFAB41-X0651-DC24V 1 CKD
24 YV1071 U40624A SOLENOID VALVE GFAB41-X0651-DC24V 1 CKD
25 YV1201 U40624A SOLENOID VALVE GFAB41-X0651-DC24V 1 CKD
26
YV1030,
YV1031
U49203B SOLENOID VALVE 4GB240-08-B-3 1 CKD
27 * U40452A SPEED CONTROLLER SC3W-8-8 2 CKD
28 * U41467A AIR CYLINDER HCM-LB-40B-595 1 CKD
29 * U41465A AIR CYLINDER HCM-LB-40B-795 1 CKD
30 * U41470A AIR CYLINDER HCM-LB-40B-915 1 CKD
31 * *
PRESSURE REDUCING
VALVE
RA800-8-PGB 2 CKD
32 * *
METERLIN VALVE WITH
SILENCER
2MW2-8A 4 CKD
