Cisco ONS 15454 Procedure Guide, R5.0
August 2005
Chapter 6 Create Circuits and VT Tunnels
NTP-A192 Create a Circuit for an E-Series Card in Port-Mapped Mode
Step 22 Click Next.
Step 23 In the left pane of the Circuit Routing Preferences panel, confirm that the following information is
correct:
• Circuit name
• Circuit type
• Circuit size
• ONS nodes
Step 24 If the information is not correct, click the Back button and repeat Steps 8 through 23 with the correct
information. If the information is correct, check Route Automatically.
Step 25 Click Finish.
Step 26 Complete the “DLP-A221 Provision E-Series Ethernet Ports for VLAN Membership” task on
page 19-14.
Step 27 Complete the “NTP-A146 Test E-Series Circuits” procedure on page 6-72.
Stop. You have completed this procedure.
NTP-A192 Create a Circuit for an E-Series Card in Port-Mapped
Mode
Step 1 Complete the “DLP-A60 Log into CTC” task on page 17-66 at the node where you will create the circuit.
If you are already logged in, continue with Step 4.
Step 2 Provision the Ethernet cards that will carry the circuit for port-mapped mode. See the “DLP-A246
Provision E-Series Ethernet Card Mode” task on page 19-29.
Step 3 Complete the “DLP-A220 Provision E-Series Ethernet Ports” task on page 19-13.
Step 4 From the View menu, choose Go to Network View.
Step 5 Click the Circuits tab and click Create.
Step 6 In the Create Circuits dialog box, complete the following fields:
• Circuit Type—Choose STS.
• Number of Circuits—Leave the default unchanged (1).
• Auto-ranged—Unavailable.
Purpose This procedure creates an E-Series point-to-point SONET circuit with an
E-Series card in port-mapped mode.
Tools/Equipment An E-Series Ethernet card must be installed at each end of the circuit and
configured in port-mapped mode.
Prerequisite Procedures NTP-A127 Verify Network Turn Up, page 6-4
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
