Page 6-332
Programming
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
System Timers and Limits
E&M Handshake Timeout 5000 2-20000 millisec.
(0.002-20 sec.)
Determines the maximum length of a valid hand-
shake signal. Used only on Wink-Start and Dial-Delay
circuits.
E&M Hookflash Duration 600 2-10000 millisec.
(0.002-10 sec.)
Determines the length of hookflashes (recalls) sent to
the remote circuits.
E&M Hookflash Recogni-
tion
300 2-10000 millisec.
(0.002-10 sec.)
Determines the minimum length of recognizable
hookflashes (recalls) from the remote circuit.
E&M Inpulse-Dial Inter-
digit Pause Recognition
300 2-10000 millisec. This is the minimum pause allowed between incom-
ing pulse-dial signals sent from the remote circuit. It
allows the system to recognize the separation
between digits.
E&M Off-Hook Debounce 10 2-500 millisec.
(0.002-0.5 sec.)
This is the minimum amount of time the remote cir-
cuit must be off hook before the E&M circuit will rec-
ognize another on-hook/off-hook transition.
E&M On-Hook Debounce 10 2-500 millisec.
(0.002-0.5 sec.)
This is the minimum amount of time the remote cir-
cuit must be on hook before the E&M circuit will rec-
ognize another off-hook/on-hook transition.
E&M Outpulse-Dial Inter-
digit Pause
700 2-10000 millisec.
(0.002-10 sec.)
This is the minimum amount of time the E&M circuit
will pause between pulse-dial digits when dialing.
E&M Outpulse-Dial Inter-
pulse Pause
40 2-500 millisec.
(0.002-0.5 sec.)
This is the length of time the E&M circuit will pause
between pulse-dial digits when dialing.
E&M Post-Seize Delay 65 2-500 millisec.
(0.002-0.5 sec.)
This is the minimum allowed time between the recog-
nition of a seizure and the beginning of digit valida-
tion. Used only for Immediate-Dial circuits.
E&M Post-Signal Delay 30 2-500 millisec.
(0.002-0.5 sec.)
This is the minimum allowed time between the end of
a handshake and the beginning of digit validation.
Used only for Wink-Start and Dial-Delay circuits.
E&M Pulse Hold 60 2-500 millisec.
(0.002-0.5 sec.)
This is the maximum length of a pulse-dial signal that
is dialed by the E&M circuit.
E&M Ready Timeout 4000 2-20000 millisec.
(0.002-20 sec.)
On a Wink-Start circuit: This is the maximum time
the E&M circuit will wait for a “Digit Register Ready”
command before initiating the Wink-Start handshake.
On a Dial-Delay circuit: This is the maximum time
the E&M circuit will wait for a “Digit Register Ready”
command before the Dial-Delay signal is terminated.
E&M Receive Handshake
Delay
20 2-500 millisec.
(0.002-0.5 sec.)
This is the minimum time required, after seizure,
before an incoming handshake signal can be recog-
nized. Used only for Wink-Start and Dial-Delay cir-
cuits. If a Wink or Dial Delay signal is detected within
this time, the outgoing call is blocked.
E&M Seizure Debounce 2 2-500 millisec.
(0.002-0.5 sec.)
Determines the minimum amount of time the remote
circuit must remain off hook before the E&M circuit
validates the incoming call.
Table 6-38: System Timers (Continued)
Timer
Default
Value
Range Purpose
