Page 6-422
Programming
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
SMDR Buffer
11. SMDR BUFFER
NOTE: SMDR buffering is not supported by Enterprise Messaging.
11.1 The Voice Processor will buffer SMDR records from the local node and records that are
sent from other nodes in the network. The following information can be programmed for the
Voice Processor SMDR Buffering application.
• Clear SMDR Buffer
• SMDR Buffer Size
• SMDR Buffer-Box Bit Rate - COM 2
• Enable SMDR Buffering
11.2 Clear The SMDR Buffer: (Not available in stand-alone programming sessions.) Dur-
ing a direct-connect or remote programming session, you can clear the data in the SMDR
buffer. To clear the buffer, right-click on
SMDR Buffer in the Voice Processor directory and
select
Clear. A window appears that asks if you are sure you want to clear the SMDR buffer.
Select
Yes to continue or select Cancel to leave the buffer unchanged. If you chose to clear, an
information window will appear to tell you that the buffer has been cleared. Select
OK to con-
tinue.
11.3 Programming the SMDR Buffer: You can program the following fields:
• SMDR Buffer Size: To determine how much of the Voice Processing PC disk space
will be devoted to SMDR buffering, select the current value and enter or scroll to the
desired number of megabytes (0-20). Then press
ENTER or click on another field to
save the change.
— If you attempt to set the buffer size to a value higher than your available disk
space, you will receive a warning message that says, “The Voice Processing PC
did not have enough disk space to set the buffer size to XXX megabytes. The cur-
rent buffer size is now 0 megabytes. Note: If there was data in the buffer, the data
is still intact.”; select
OK to continue and reset the buffer to a valid size.
— If you change the size of the buffer, a window appears that tell you that the buffer
will be cleared and asks if you want to continue. Select
Yes to complete the resiz-
ing or select
No to leave the buffer and buffer size unchanged.
• SMDR Buffer Box Bit Rate: To determine the rate of output from the buffer box port
(COM2), select this drop-down list box. The available rates are 300, 1200, 2400, 4800,
9600, and 19200. Then press
ENTER or click on another field to save the change.
• Enable SMDR Buffering: (Buffer size must be greater than 0 for this check box to be
selected.) To enable the SMDR Buffering option, select the check box to place a check
mark in it. Then press
ENTER or click on another field to save the change. To disable
SMDR buffering, select the check box again to remove the check mark.
