Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-216
Sample Back of Assembled Voice Processing PC
Figure 3-95. Sample Back of Assembled Voice Processing PC
SAMPLE CARD SLOT
ARRANGEMENT
POWER CABLE
CONNECTOR
AUDIO INTERFACE
CARD
NOTE: Depending on the model of PC being used, the sample card slot arrangement and connector
locations shown above could vary somewhat.
TO RS-232C
(COM1)
MSE
KBD
PARALLEL
TO PC
(COM2)
VIDEO CARD
NETWORK
INTERFACE CARD
1ST VPC
2ND VPC
OPTIONAL
FAX CARD
TO CPU
(PCM PORT)
TO OPC
(PCM PORT)
