Inter-Tel AXXESS - 14 Port Usage Summary

Page F-21
Appendix F – Network Topology
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Port Usage Summary
APPENDICES
.
Table F-1. Port Assignments
Port TCP/UDP
Port
Name
Inter-Tel Products Access to:
21 TCP FTP
• System Manager
• Engineering File Transfer Protocol
(FTP)
File downloads and file transfers,
Board or Upload Utility
22 TCP SSH
• Inter-Tel 5000
• Enterprise Conferencing (EC)
Used for remote access to IP prod-
ucts
1
23 TCP Telnet
• Call Processing Card (CPC)
• IP Resource Card (IPRC)
• IP Card (IPC)
• Inter-Tel 5000
• System Manager
• Unified Communicator (UC)
•EC
• IP endpoints
• Web Conference
System programming and general
information
1
25 TCP SMTP
• System Manager
• AVDAP
• Interactive Voice Response (IVR)
• Contact Center Suite (CCS)
• Enterprise Messaging (EM)
Used for sending mail
25 TCP SMTP EM (Outbound) Simple Mail Transfer Protocol
(SMTP) delivery for Unified Messag-
ing (UM)
42 TCP/UDP WINS Most Inter-Tel products Name resolution IP to Equipment
Name
53 TCP/UDP DNS Most Inter-Tel products Name resolution IP to Domain Name
67 UDP DHCP Most Inter-Tel products Dynamic IP Allocation
67 UDP BootP Inter-Tel products are not BootP serv-
ers only clients except v1.X IPRC
Dynamic Allocation using the BootP
process
68 UDP BootP Inter-Tel IPRC and IP endpoints Client side of BootP
69 TCP TFTP IP products and IP endpoints Used for uploading software and firm-
ware updates
80 TCP HTTP
•CPC
•IPRC
•IPC
• Inter-Tel 5000
• System Manager
•UC
•EC
• IP endpoints
• Web Conference
Various features depending on the
product
