Inter-Tel AXXESS - Figure 3-78 Original IP Resource Card (IPRC)

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-150
Original IP Resource Card (IPRC)
Figure 3-78. Original IP Resource Card (IPRC)
MAKE-BUSY SWITCH
RS-232-C JACK (1)
RJ-45 CONNECTOR
(LAN)
LINK STATUS LED INDICATORS
LNK (GREEN)
XMT (GREEN)
CARD ON-LINE (GREEN)
CIRCUIT BUSY (YELLOW)
MAKE BUSY (YELLOW)
HALTED (RED)
DUPLEX (GREEN)
COLLISION (YELLOW)
100BASE-T (GREEN)
LED INDICATORS
LED INDICATORS
RS-232-C JACK (2)
U22
PAL
NOTE: For purposes of detail, this drawing does not show the EMI shield attached to
the front of the card.
