Inter-Tel AXXESS - Figure 3-30 SLC Block Cable Terminations (U.S.)

Page 3-55
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
SLC Block Cable Terminations (U.S.)
INSTALLATION
3
Figure 3-30. SLC Block Cable Terminations (U.S.)
NOTE: For simplicity, this figure shows single-line sets and playback devices being installed using one-
pair cable and four-conductor modular jacks. Of course, if three-pair cable and six-conductor modular
jacks are used instead (as is recommended), extra terminal blocks and the use of cross-connect wiring
techniques are required.
60M1-50-TYPE
BLOCK
(PART OF MDF)
AMPHENOL-
TYPE
CONNECTOR
SINGLE-
LINE
CARD
MODULAR
JACK
ASSEMBLY
SLC
1.1
1.2
1.8
W/BL
BL/W
W/O
O/W
R/G
G/R
BR/V
V/S
S/V
TIP
RING
TIP
RING
AC RING RET.
W/BL TIP
DO NOT USE
DO NOT USE
G
R
Y
BK
G
R
Y
BK
1.3
BL/W RING
AC RING SIG.
NOT USED
R/BR
BR/R
TO SINGLE-
PLAYBACK
DEVICE
LINE SET OR
TO SINGLE-
PLAYBACK
DEVICE
LINE SET OR
W/G
G/W
TIP
RING
1.1
1.2
1.8
1.3
TIP
RING
NOT USED
NOT USED
W/BL TIP
BL/W RING
