Inter-Tel AXXESS - Figure 3-48 CPU64 or CPU128 Card

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-98
CPU64 or CPU128 Card
Figure 3-48. CPU64 or CPU128 Card
CPU CARD
BATTERY
CHECK SWITCH
BATTERY BACK-UP
(BBU) STRAP
BATTERY
TEST POINT
LED
INDICATORS
BATTERY
TEST POINT
DB15 PCM
CONNECTOR
RS232
CONNECTOR
RESET
SWITCH
MUSIC
CONNECTOR
MU-LAW/A-LAW
STRAP
RS232
CONNECTORS
RELAY
CONNECTOR
NOTE: For purposes of detail, this drawing does
not show the EMI shield attached to the front edge
of the card.
MEMORY MAP
PAL
LITHIUM BATTERY
FEATURE-UNIT
PAL (U4)
OFF/ON
TP1 (VBAT+)
CPU ACTIVE (GREEN)
DATABASE ERROR (RED)
MINOR ALARM (YELLOW)
EXT. CLOCK ACTIVE (GREEN)
BATTERY OFF (RED)
TP2 (VBAT-)
CPU SERIAL PORT 1
CPU SERIAL PORT 2
CPU SERIAL PORT 3
TO VOICE PROCESSING PC
AUDIO INTERFACE CARD (AIC)
EXTERNAL
PAGING PORT
OR EVMC DB15 PCM CONNECTOR
