Inter-Tel AXXESS - Figure 3-83 New EVMC

Page 3-159
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
New EVMC
INSTALLATION
3
Figure 3-83. New EVMC
LEDs
MONITOR
CONNECTOR
KEYBOARD
CONNECTOR
PARALLEL
PORT
SERIAL
RS232-C
TO CPU
DB15 PCM
CONNECTOR
MAILBOX SECURITY PAL (U23)
DSPM
CONNECTOR FOR SECOND
DSPM CARD
CARD ON-LINE
OK TO REMOVE CARD
POWER
MOUSE
CONNECTOR
(Ports 1-4)
(Ports 5-8)
CARD
DOWN BUTTON
POWER
CONNECTOR
FLOPPY DRIVE
(Not Used)
(for 32, 64 or 200 mailboxes)
CONNECTOR
FLOPPY DRIVE
HARD DRIVE
NOTE: For purposes of detail, this drawing does not show the EMI shield attached to the front edge of the card.
DB9 SERIAL
