Inter-Tel AXXESS - Figure 3-61 T1 C;E1 C and Optional PRI Daughter Card

Page 3-125
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
T1C/E1C and Optional PRI Daughter Card
INSTALLATION
3
Figure 3-61. T1C/E1C and Optional PRI Daughter Card
LED INDICATORS
MAKE-BUSY SWITCH
SERIAL PORT JACK
SPECIAL
SOFTWARE
COMPONENTS
T1/PRI
JACK
BANTAM TEST JACK
T1/PRI SPAN DB15
CONNECTOR
OPTIONAL PRIMARY
RATE INTERFACE
(PRI) DAUGHTER CARD
CARD ON-LINE (GREEN)
CIRCUIT BUSY (YELLOW)
RED ALARM (RED)
YELLOW ALARM (YELLOW)
BLUE ALARM (YELLOW)
REFERENCE CLOCK (GREEN)
MAKE BUSY (YELLOW)
CARD HALTED (RED)
RCV
XMT
U5
U4
NOTE: For purposes of detail, this drawing does not show the EMI shield attached to the front edge of the card.
or E1/PRI SPAN
