Inter-Tel AXXESS - Figure 3-9 LGC;LSC Block Cable Terminations-Method a (U.S. Only)

Page 3-27
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
LGC/LSC Block Cable Terminations—Method A (U.S. Only)
INSTALLATION
3
Figure 3-9. LGC/LSC Block Cable Terminations—Method A (U.S. Only)
LGC/LSC
LOOP/GROUND
START CARD OR
LOOP START CARD
AMPHENOL-
TYPE
CONNECTOR
66m1-50-TYPE
BLOCK
(PART OF MDF)
TO
TELCO
RJ
W/BL
BL/W
W/O
O/W
R/G
G/R
TIP
RING
TIP
RING
TIP
RING
6.1.1
6.2.1
NOTE: Circuits 1-4 (06.01.01-06.04.01) above are used by the LGC/LSC itself. If a Daughter card is
attached, it uses circuits 5-8 (06.05.01-06.08.01).
6.1.1
6.2.1
BR/V
V/S
S/V
6.8.1
6.8.1
