Example of a BRS Card Trunk Side Passive Bus Setup
INSTALLATION
3
Figure 3-70. Example of a BRS Card Trunk Side Passive Bus Setup
ISDN Circuit
U Interface
ISDN
Video Conference Unit
ISDN
Router
NT1
ISDN Modem
ISDN Telephones
All devices are an S/T Interface
on the multiple side.
Passive Bus supports up to
8 divices
Trunk Port on the
BRS Card with
TEI set to Automatic.
Phone System using the
BRS Trunk Port
Point-to-Multipoint Setup
