Inter-Tel AXXESS - Figure 3-24 AKSC Block Cable Terminations (U.S.)

Page 3-49
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
AKSC Block Cable Terminations (U.S.)
INSTALLATION
3
Figure 3-24. AKSC Block Cable Terminations (U.S.)
60M1-50-TYPE
BLOCK
(PART OF MDF)
AMPHENOL-
TYPE
CONNECTOR
ANALOG
KEYSET
CARD
MODULAR
JACK
ASSEMBLY
AKSC
1.1
1.2
1.1
1.2
W/BL
BL/W
W/O
O/W
G
R
Y
BK
W/G
G/W
V/O
O/V
V/G
G/V
V/BR
BR/V
1.8
1.8
BL
W
G
R
Y
BK
BL
W
O/W PRI
G/W SEC
W/BL +30VDC
W/O PRI
W/G SEC
BL/W GND
W/BL +30VDC
W/O PRI
W/G SEC
+30VDC
GND
PRI
PRI
SEC
SEC
TO
ANALOG
PHONE
TO
ANALOG
PHONE
