Inter-Tel AXXESS - Table 3-7 Station Cable Terminations on the Station Blocks (U.S.)

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-58
SLC Block Cable Terminations (Europe)
Table 3-7. Station Cable Terminations on the Station Blocks (U.S.)
* The station circuit numbers shown above are for the first station card installed in the equipment
chassis. The extension numbers are the default numbers assigned to those circuits.
Amphe-
nol #
Cable
Pair
DKSC
DKSC-16/
DKSC-16+
SLC SLC-16 Circuit No.* Ext. No.*
26 W-BL TIP TIP TIP TIP 01.01.01 1000
1 BL-W RING RING RING RING
27 W-O TIP TIP TIP TIP 01.02.01 1001
2 O-W RING RING RING RING
28 W-G TIP TIP TIP TIP 01.03.01 1002
3 G-W RING RING RING RING
29 W-BR TIP TIP TIP TIP 01.04.01 1003
4 BR-W RING RING RING RING
30 W-S TIP TIP TIP TIP 01.05.01 1004
5 S-W RING RING RING RING
31 R-BL TIP TIP TIP TIP 01.06.01 1005
6 BL-R RING RING RING RING
32 R-O TIP TIP TIP TIP 01.07.01 1006
7 O-R RING RING RING RING
33 R-G TIP TIP TIP TIP 01.08.01 1007
8 G-R RING RING RING RING
34 R-BR NOT USED TIP NOT USED TIP 01.09.01 1008
9 BR-R NOT USED RING NOT USED RING
35 R-S NOT USED TIP NOT USED TIP 01.10.01 1009
10 S-R NOT USED RING NOT USED RING
36 BK-BL NOT USED TIP NOT USED TIP 01.11.01 1010
11 BL-BK NOT USED RING NOT USED RING
37 BK-O NOT USED TIP NOT USED TIP 01.12.01 1011
12 O-BK NOT USED RING NOT USED RING
38 BK-G NOT USED TIP NOT USED TIP 01.13.01 1012
13 G-BK NOT USED RING NOT USED RING
39 BK-BR NOT USED TIP NOT USED TIP 01.14.01 1013
14 BR-BK NOT USED RING NOT USED RING
40 BK-S NOT USED TIP NOT USED TIP 01.15.01 1014
15 S-BK NOT USED RING NOT USED RING
41 Y-BL NOT USED TIP NOT USED TIP 01.16.01 1015
16 BL-Y NOT USED RING NOT USED RING
42 Y-O NOT USED NOT USED NOT USED NOT USED
17 O-Y NOT USED NOT USED NOT USED NOT USED
43 Y-G NOT USED NOT USED NOT USED GND B2 (BL)
18 G-Y NOT USED NOT USED NOT USED -48V EXT (R)
44 Y-BR NOT USED NOT USED NOT USED NOT USED
19 BR-Y NOT USED NOT USED NOT USED NOT USED
45 Y-S NOT USED NOT USED NOT USED GND B1 (B)
20 S-Y NOT USED NOT USED NOT USED -72V EXT (Y)
46 V-BL NOT USED NOT USED NOT USED NOT USED
21 BL-V NOT USED NOT USED NOT USED NOT USED
47 V-O NOT USED NOT USED NOT USED NOT USED
22 O-V NOT USED NOT USED NOT USED NOT USED
48 V-G NOT USED NOT USED NOT USED NOT USED
23 G-V NOT USED NOT USED NOT USED NOT USED
49 V-BR NOT USED NOT USED NOT USED NOT USED
24 BR-V NOT USED NOT USED NOT USED NOT USED
50 V-S NOT USED +36 AC RING SIG. NOT USED
25 S-V NOT USED GROUND AC RING RET. NOT USED
