Page 3-59
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
SLC Block Cable Terminations (Europe)
INSTALLATION
3
Table 3-7. Station Cable Terminations on the Station Blocks with a U.S. System (Continued)
* The circuit numbers shown above are for the first station card in the equipment chassis. The exten-
sion numbers are the default numbers assigned to those circuits.
Amphenol # Cable Pair AKSC Circuit No.* Ext. No.*
26 W-BL +30VDC 01.01.01 1000
1BL-W GND
27 W-O PRIMARY PATH
2 O-W PRIMARY PATH
28 W-G SECONDARY PATH
3 G-W SECONDARY PATH
29 W-BR +30VDC 01.02.01 1001
4 BR-W GND
30 W-S PRIMARY PATH
5 S-W PRIMARY PATH
31 R-BL SECONDARY PATH
6 BL-R SECONDARY PATH
32 R-O +30VDC 01.03.01 1002
7O-R GND
33 R-G PRIMARY PATH
8 G-R PRIMARY PATH
34 R-BR SECONDARY PATH
9 BR-R SECONDARY PATH
35 R-S +30VDC 01.04.01 1003
10 S-R GND
36 BK-BL PRIMARY PATH
11 BL-BK PRIMARY PATH
37 BK-O SECONDARY PATH
12 O-BK SECONDARY PATH
38 BK-G +30VDC 01.05.01 1004
13 G-BK GND
39 BK-BR PRIMARY PATH
14 BR-BK PRIMARY PATH
40 BK-S SECONDARY PATH
15 S-BK SECONDARY PATH
41 Y-BL +30VDC 01.06.01 1005
16 BL-Y GND
42 Y-O PRIMARY PATH
17 O-Y PRIMARY PATH
43 Y-G SECONDARY PATH
18 G-Y SECONDARY PATH
44 Y-BR +30VDC 01.07.01 1006
19 BR-Y GND
45 Y-S PRIMARY PATH
20 S-Y PRIMARY PATH
46 V-BL SECONDARY PATH
21 BL-V SECONDARY PATH
47 V-O +30VDC 01.08.01 1007
22 O-V GND
48 V-G PRIMARY PATH
23 G-V PRIMARY PATH
49 V-BR SECONDARY PATH
24 BR-V SECONDARY PATH
50 V-S NOT USED
25 S-V NOT USED
To Next Page
