Inter-Tel AXXESS - Figure 3-55 DKSC or DKSC-16 and DKSC-16

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-112
DKSC or DKSC-16 and DKSC-16+
Figure 3-55. DKSC or DKSC-16 and DKSC-16+
LED INDICATORS
AMPHENOL-TYPE
CONNECTOR
CARD ON-LINE (GREEN)
CIRCUIT BUSY (YELLOW)
NOTE: For purposes of
detail, this drawing does not
show the EMI shield attached
to the front edge of the card.
