Connect Devices to the BRS Cards
Table 3-5. BRU Device Connections to the MDF (U.S.)
NOTE: The “NC” represents No Connection.
Amphenol Pin Color Circuit BRI Device
1 White/Blue 1 TIP 0
26 Blue/White RING 0
2 White/Orange 2 TIP 1
27 Orange/White RING 1
3 White/Green 3 TIP 2
28 Green/White RING 2
4 White/Brown 4 TIP 3
29 Brown/White RING 3
5White/Gray 5 TIP 4
30 Gray/White RING 4
6 Red/Blue 6 TIP 5
31 Blue/Red RING 5
7 Red/Orange 7 TIP 6
32 Orange/Red RING 6
8 Red/Green 8 TIP 7
33 Green/Red RING 7
9 Red/Brown NC
34 Brown/Red NC
10 Red/Gray NC
35 Gray/Red NC
11 Black/Blue NC
36 Blue/Black NC
12 Black/Orange NC
37 Orange/Black NC
13 Black/Green NC
38 Green/Black NC
14 Black/Brown NC
39 Brown/Black NC
15 Black/Gray NC
40 Gray/Black NC
16 Yellow/Blue NC
41 Blue/Yellow NC
17 Yellow/Orange NC
42 Orange/Yellow NC
18 Yellow/Green NC
43 Green/Yellow NC
19 Yellow/Brown NC
44 Brown/Yellow NC
20 Yellow/Gray NC
45 Gray/Yellow NC
21 Violet/Blue NC
46 Blue/Violet NC
22 Violet/Orange NC
47 Orange/Violet NC
23 Violet/Green NC
48 Green/Violet NC
24 Violet/Brown NC
49 Brown/Violet NC
25 Violet/Gray NC
50 Gray/Violet NC
