Inter-Tel AXXESS - Figure 3-52 PCM-F Card and Attached CPU020-X Card

Page 3-107
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
PCM-F Card and Attached CPU020-X Card
INSTALLATION
3
Figure 3-52. PCM-F Card and Attached CPU020-X Card
PCM-F CARD
LED
INDICATORS
DB15 PCM
CONNECTOR
RESET
SWITCH
RS232
CONNECTORS
U25
U41
LED
INDICATORS
EXTERNAL
PAGING PORT
CPU ACTIVE (GREEN)
MINOR ALARM (YELLOW)
“X” SOFTWARE
COMPONENTS
U41 is at the far edge of the card
STANDOFF
FIBER RECEIVE
JACK
FIBER TRANSMIT
JACK
NOTE: For purposes of detail, this drawing
does not show the EMI shield attached to the
front edge of the card.
NOT USED
EXT. CLOCK ACTIVE (GREEN)
REMOTE SYNC (GREEN)
LOCAL SYNC (GREEN)
TO FIBER TRANSMIT JACK ON
OTHER PCM-F CARD
TO FIBER RECEIVE JACK ON
OTHER PCM-F CARD
CPU020-X CARD
MUSIC JACK
NOT USED
CPU SERIAL PORT 4
A/MU LAW
SWITCH
