Inter-Tel AXXESS - Figure 3-63 BRS Card

Page 3-131
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
BRS Card
INSTALLATION
3
Figure 3-63. BRS Card
LED INDICATORS
MAKE-BUSY
SWITCH
RS232 PORT
AMPHENOL-TYPE
CONNECTOR
EXTERNAL POWER
CONNECTOR
JUMPER IN DEFAULT
POSITION
NOTE: For purposes of detail, this
drawing does not show the EMI
shield attached to the front edge of
the card.
1
2
7
8
JUMPER IN POSITION
TO USE EXTERNAL POWER
(EXTERNAL SUPPLY
2
1
7
8
PROVIDING POWER)
CARD ON LINE
CIRCUIT BUSY
CLOCK REFERENCE
MAKE BUSY
HALTED
J7
PIN 1
PIN 2
-48V
-48V RET
EXTERNAL POWER SUPPLY
CIRCUIT 1
CIRCUIT 2
CIRCUIT 3
CIRCUIT 4
CIRCUIT 5
CIRCUIT 6
CIRCUIT 7
CIRCUIT 8
J4
WRITE PROTECT JUMPER
(for Boot Code)
LOCK
