Inter-Tel AXXESS - Mini-DSS Installation; Figure; Model 8560 with Attached Mini-DSS

Page 3-207
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Mini-DSS Installation
INSTALLATION
3
Figure 3-93. Mini-DSS Installation
Figure 3-94. Model 8560 with Attached Mini-DSS
NOTE: For illustrative purposes, the base on the phone is not shown.
Mini-DSS
(Bottom)
8560 Phone
(Bottom)
Top Access Panel
Cable Pin Connector
Bottom Access Panel
Cable
(1¾”)
Mini-DSS
Faceplate
Phone Facemats
Mini-DSS
Facemats
