On-Site Krone Connections for BRS (Europe Only)
Table 3-6. BRS Device Connections to the MDF (Europe)
Amphenol Pin Color Circuit BRI Device
1 White/Blue 1 TXN0
26 Blue/White TXP0
2 White/Orange RXP0
27 Orange/White RXN0
3 White/Green -48V F0
28 Green/White CIRCUIT POWER (Only used for older devices) -48V RET
4 White/Brown 2 TXN1
49 Brown/White TXP1
5 White/Gray RXP1
30 Gray/White RXN1
6 Red/Blue -48V F1
31 Blue/Red CIRCUIT POWER (Only used for older devices) -48V RET
7 Red/Orange 3 TXN2
32 Orange/Red TXP2
8 Red/Green RXP2
33 Green/Red RXN2
9 Red/Brown -48V F2
34 Brown/Red CIRCUIT POWER (Only used for older devices) -48V RET
10 Red/Gray 4 TXN3
35 Gray/Red TXP3
11 Black/Blue RXP3
36 Blue/Black RXN3
12 Black/Orange -48V F3
37 Orange/Black CIRCUIT POWER (Only used for older devices) -48V RET
13 Black/Green 5 TXN4
38 Green/Black TXP4
14 Black/Brown RXP4
39 Brown/Black RXN4
15 Black/Gray -48V F4
40 Gray/Black CIRCUIT POWER (Only used for older devices) -48V RET
16 Yellow/Blue 6 TXN5
41 Blue/Yellow TXP5
17 Yellow/Orange RXP5
42 Orange/Yellow RXN5
18 Yellow/Green -48V F5
43 Green/Yellow CIRCUIT POWER (Only used for older devices) -48V RET
19 Yellow/Brown 7 TXN6
44 Brown/Yellow TXP6
20 Yellow/Gray RXP6
45 Gray/Yellow RXN6
21 Violet/Blue -48V F6
46 Blue/Violet CIRCUIT POWER (Only used for older devices) -48V RET
22 Violet/Orange 8 TXN7
47 Orange/Violet TXP7
23 Violet/Green RXP7
48 Green/Violet RXN7
24 Violet/Brown -48V F7
49 Brown/Violet CIRCUIT POWER (Only used for older devices) -48V RET
25 Violet/Slate -48V
50 Slate/Violet CARD POWER (Input from BRS PSU) -48V RET
