Inter-Tel AXXESS - Figure 5-6 Executive Keymap (V6.X); Keymap (V7.0 and Later)

Page 5-136
System Features
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Executive Keymap (v6.x)
Figure 5-6. Executive Keymap (v6.x)
Figure 5-7. 8500 Keymap (v7.0 and Later)
NOTE: To program the 8500 (24 buttons) on a system using software v3.0-6.X, use the Stan-
dard keymap (24 buttons), as shown in the following figure. Buttons designated with xxx do not
correspond to any buttons on the v7.0 and later phones and will not function on earlier software
versions.
