Inter-Tel AXXESS - Figure D-1 Call Processing Card (CPC

Page D-12
Appendix D — CPC64/CPU64 Configuration
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Call Processing Card (CPC)
Figure D-1. Call Processing Card (CPC)
NOTE: For purposes of detail, this drawing does not show the electromagnetic interference
(EMI) shield attached to the front end of the card.
LED
INDICATORS
* BUTTON
MUSIC
CONNECTOR
EXTERNAL
PAGING PORT
10/100BASE-T
ETHERNET PORT
RS-232
CONNECTORS
CONNECTOR
RELAY
DB15 PCM
CONNECTOR
TO VOICE PROCESSING PC,
AUDIO INTERFACE CARD (AIC),
OR EVMC DB15 PCM CONNECTOR
RECHARGEABLE
BATTERY AREA
CPU Active
DB Error
MNR
MDM
100
DBX
Battery
