SLC Block Cable Terminations (Europe)
Table 3-7. Station Cable Terminations on the Station Blocks with a U.S. System (Continued)
* The circuit numbers shown above are for the first station card in the equipment chassis. The exten-
sion numbers are the default numbers assigned to those circuits.
Amphenol # Cable Pair EKSC Circuit No.* Ext. No.*
26 W-BL TT 01.01.01 1000
1BL-WTR
27 W-O RT
2O-WRR
28 W-G TT 01.02.01 1001
3 G-W TR
29 W-BR RT
4 BR-W RR
30 W-S TT 01.03.01 1002
5S-WTR
31 R-BL RT
6BL-RRR
32 R-O TT 01.04.01 1003
7 O-R TR
33 R-G RT
8 G-R RR
34 R-BR TT 01.05.01 1004
9BR-RTR
35 R-S RT
10 S-R RR
36 BK-BL TT 01.06.01 1005
11 BL-BK TR
37 BK-O RT
12 O-BK RR
38 BK-G TT 01.07.01 1006
13 G-BK TR
39 BK-BR RT
14 BR-BK RR
40 BK-S TT 01.08.01 1007
15 S-BK TR
41 Y-BL RT
16 BL-Y RR
42 Y-O TT 01.09.01 1008
17 O-Y TR
43 Y-G RT
18 G-Y RR
44 Y-BR TT 01.10.01 1009
19 BR-Y TR
45 Y-S RT
20 S-Y RR
46 V-BL TT 01.11.01 1010
21 BL-V TR
47 V-O RT
22 O-V RR
48 V-G TT 01.12.01 1011
23 G-V TR
49 V-BR RT
24 BR-V RR
50 V-S NOT USED
25 S-V NOT USED
