Network Planning Sheet
Table A-12. IP Networking Planning Worksheet
The following is an example of a completed IP Private Networking Planning sheet. A blank sheet is provided on the following page for your use.
*The system automatically assigns the Node IP Connection Group extension numbers.
Node 1 Node 2 Node 3 Node 4 Node 5 Node 6 Node 7 Node 8 Node 9
Extensions
1100-1199 1200-1299 1300-1399 1400-1499 1500-1599 1600-1699 1700-1799 1800-1899
1900-1999
Area Code
602 514 404 713 216 914 802 440
203
Nodes (Node Route Group)
97001 97002 97003 97004 97005 97006 97007 97008
97009
IP Connection Group
P6001 P6002 P6003 P6004 P6005 P6006 P6007 P6008
P6009
Node IP Con- nection Group*
P8000 P8001 P8002 P8003 P8004 P8005 P8006
P8007
IPRC (Net- working)
192.168.0.41 192.168.0.42 192.168.0.43 192.168.0.44 192.168.0.45 192.168.0.46 192.168.0.47 192.168.0.48
192.168.0.49
IPRC (Station)
192.168.0.51 192.168.0.52 192.168.0.53 192.168.0.54 192.168.0.55 192.168.0.56 192.168.0.57 192.168.0.58
192.168.0.59
MGCP
192.168.0.61 192.168.0.62 192.168.0.63 192.168.0.64 192.168.0.65 192.168.0.66 192.168.0.67 192.168.0.68
192.168.0.69
IPPhone Plus
192.168.0.71 192.168.0.72 192.168.0.73 192.168.0.74 192.168.0.75 192.168.0.76 192.168.0.77 192.168.0.78
192.168.0.79
Subnet
255.255.252.0 255.255.252.0 255.255.252.0 255.255.252.0 255.255.252.0 255.255.252.0 255.255.252.0 255.255.252.0
255.255.252.0
Default Gate- way
192.168.0.200 192.168.0.200 192.168.0.200 192.168.0.200 192.168.0.200 192.168.0.200 192.168.0.200 192.168.0.200
192.168.0.200
