Inter-Tel AXXESS - Figure 3-57 SLC and Optional LOC

Page 3-117
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
SLC and Optional LOC
INSTALLATION
3
Figure 3-57. SLC and Optional LOC
LED INDICATORS
AMPHENOL-TYPE
CONNECTOR
CARD ON-LINE (GREEN)
CIRCUIT BUSY (YELLOW)
ONBOARD RING
GENERATOR
RING GENERATOR
SELECTION JUMPERS
(Older boards have only J701)
OPTIONAL LAMP
OPTION CARD (LOC)
NOTE: For purposes of detail, this drawing does not show the EMI shield attached to the front edge of the card.
J7
J701
J702
EXT.
INT.
EXT.
INT.
