Inter-Tel AXXESS - Figure 2-8 Original Basic Equipment Chassis

Page 2-105
Specifications
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Original Basic Equipment Chassis
SPECIFICATIONS
2
Figure 2-8. Original Basic Equipment Chassis
POWER SUPPLY UNIT
BACKPLANE
MOUNTING HOLES
ON
OFF
POWER SUPPLY
550.0102
+24v1
+5v
+24v2 -5v
CPU
1(9
)
2(10
)
3(11)
4(12)
5(13) 6(14) 7(15)
SLOTS
