SLC Block Cable Terminations (Europe)
INSTALLATION
3
Table 3-8. DKSC/SLC/LSC-D Cable Terminations on the MDF Blocks (Europe)
Single Block Cables for use with DKSC, SLC, & LSC-D
Cable Pair Color Plug Pin No. Block No. Block Pair Circuit
1
White/Blue
Blue/White
1
26
1
1 01.01
2
White/Orange
Orange/White
2
27
2 02.01
3
White/Green
Green/White
3
28
3 03.01
4
White/Brown
Brown/White
4
29
4 04.01
5
White/Gray
Gray/White
5
30
5 05.01
6
Red/Blue
Blue/Red
6
31
6 06.01
7
Red/Orange
Orange/Red
7
32
7 07.01
8
Red/Green
Green/Red
8
33
8 08.01
9
Red/Brown
Brown/Red
9
34
9
Do not
use
10
Red/Gray
Gray/Red
10
35
10
