SLC Block Cable Terminations (Europe)
Table 3-9. DKSC-16 Cable Terminations on the MDF Blocks (Europe)
Twin Block Cables for use with DKSC-16
Cable Pair Color Plug Pin No. Block No. Block Pair Circuit
1
White/Blue
Blue/White
1
26
1
1 01.01
2
White/Orange
Orange/White
2
27
2 02.01
3
White/Green
Green/White
3
28
3 03.01
4
White/Brown
Brown/White
4
29
4 04.01
5
White/Gray
Gray/White
5
30
5 05.01
6
Red/Blue
Blue/Red
6
31
6 06.01
7
Red/Orange
Orange/Red
7
32
7 07.01
8
Red/Green
Green/Red
8
33
8 08.01
9
Red/Brown
Brown/Red
9
34
9 09.01
10
Red/Gray
Gray/Red
10
35
10 10.01
11
Black/Blue
Blue/Black
11
36
2
1 11.01
12
Black/Orange
Orange/Black
12
37
2 12.01
13
Black/Green
Green/Black
13
38
3 13.01
14
Black/Brown
Brown/Black
14
39
4 14.01
15
Black/Gray
Gray/Black
15
40
5 15.01
16
Yellow/Blue
Blue/Yellow
16
41
6 16.01
17
Yellow/Orange
Orange/Yellow
17
42
7
Do not
use
18
Yellow/Green
Green/Yellow
18
43
8
19
Yellow/Brown
Brown/Yellow
24
25
9
20
Yellow/Gray
Gray/Yellow
49
50
10
