Inter-Tel AXXESS - Figure 3-58 SLC-16 or SLC-16+ and Optional LOC-16; Figure

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-118
SLC-16 or SLC-16+ and Optional LOC-16
Figure 3-58. SLC-16 or SLC-16+ and Optional LOC-16
LED
AMPHENOL-TYPE
CONNECTOR
CARD ON-LINE (GREEN)
CIRCUIT BUSY (YELLOW)
OPTIONAL LAMP
OPTION CARD
NOTE: For purposes of detail, this drawing does not show the EMI shield attached to the front edge of the card.
(LOC-16)
INDICATORS
-72VDC OK (GREEN)
-48VDC OK (GREEN)
LOW VOLTAGE
SELECTION STRAP
J3
J4
LOW
NORM
J6
J5
RINGING POWER
SUPPLY CONNECTOR
J7
