On-Site Krone Connections for BRS (Europe Only)
INSTALLATION
3
Figure 3-19. On-Site Krone Connections for BRS (Europe Only)
Gray/Violet
Violet/Gray
3rd Block for BRS
White/Blue
Blue/White
8
9
0
(New Cable Red)
(New Cable Black)
