Appendix D — CPC64/CPU64 Configuration
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page D-17
CPU64 Card
APPENDICES
Figure D-2. CPU64 Card
CPU CARD
BATTERY
CHECK SWITCH
BATTERY BACK-UP
(BBU) STRAP (J2)
BATTERY
TEST POINT
LED
INDICATORS
BATTERY
TEST POINT
DB15 PCM
CONNECTOR
RS232
CONNECTOR
RESET
SWITCH
MUSIC
CONNECTOR
MU-LAW/A-LAW
STRAP (J14)
RS232
CONNECTORS
RELAY
CONNECTOR
NOTE: For purposes of detail, this drawing
does not show the EMI shield attached to the
front edge of the card.
MEMORY MAP
PAL
LITHIUM BATTERY
FEATURE-UNIT
PAL (U4)
OFF/ON
TP1 (VBAT+)
CPU ACTIVE (GREEN)
DATABASE ERROR (RED)
MINOR ALARM (YELLOW)
EXT. CLOCK ACTIVE (GREEN)
BATTERY OFF (RED)
TP2 (VBAT-)
CPU SERIAL PORT 1
CPU SERIAL PORT 2
CPU SERIAL PORT 3
TO EVMC OR
AUDIO INTERFACE CARD (AIC)
EXTERNAL
PAGING PORT
VOICE PROCESSING PC
