Inter-Tel AXXESS - Figure 4-1 Example of Voice Processing Unit Network

Page 4-11
Voice Processing Features
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Example of Voice Processing Unit Network
4
VOICE
PROCESSING
Figure 4-1. Example of Voice Processing Unit Network
CHANDLER
DENVER HOUSTON
:
Network Node Table:
Local Mailbox Node # Remote Mailbox
1700 1 200
1712 1 212
1721 2 1421
2001 1 None
2002 2 None
Node Description System # Type
1 Denver 1-303-790-7799 AMIS
2 Houston 1-713-867-7600 TCP/IP
Network Node Table:
Local Mailbox Node # Remote Mailbox
1600 1 200
1612 1 212
1700 2 1200
Node Description System # Type
1 Denver 1-303-790-7799 AMIS
2 Chandler 1-480-961-9000 TCP/IP
System Number: (303) 790-7799
Local Mailboxes: 200-299
Non-Inter-Tel Voice Mail System Using AMIS
