DKSC-16 Block Cable Terminations for Phones (U.S.)
INSTALLATION
3
Figure 3-22. DKSC-16 Block Cable Terminations for Phones (U.S.)
60M1-50-TYPE
BLOCK
(PART OF MDF)
AMPHENOL-
TYPE
CONNECTOR
DIGITAL
KEYSET
CARD
MODULAR
JACK
ASSEMBLY
DKSC
1.1.1
1.2.1
1.1.1
1.2.1
W/BL
BL/W
W/O
O/W
Y/BL
BL/Y
BR/V
S/V
TIP
RING
TIP
RING
RING
TIP
G
R
Y
BK
G
R
Y
BK
16-PORT
NOTE: For simplicity, this figure shows digital phones being installed using one-pair cable and four-con-
ductor modular jacks. Of course, if two-pair cable or three-pair cable is used instead, extra terminal blocks
and the use of cross-connect wiring techniques are required. Note that tip and ring are connected to the
second pair of terminals (black and yellow) on the modular jack.
TO DIGITAL
PHONE OR
SINGLE-LINE
ADAPTER
TO DIGITAL
PHONE OR
SINGLE-LINE
ADAPTER
1.16.1
1.16.1
25 GROUND
+36 VDC
TIP
RING
RING
TIP
V/S
