Newer IP Resource Card (IPRC)
INSTALLATION
3
Figure 3-79. Newer IP Resource Card (IPRC)
NOTE: For purposes of detail, this drawing does not show the EMI shield attached to the front
of the card.
MAKE-BUSY SWITCH
RS-232-C JACK (1)
RJ-45 CONNECTOR
(LAN)
LINK STATUS LED INDICATORS
LNK (GREEN)
XMT (GREEN)
CARD ON-LINE (GREEN)
CIRCUIT BUSY (YELLOW)
MAKE BUSY (YELLOW)
HALTED (RED)
DUPLEX (GREEN)
COLLISION (YELLOW)
100BASE-T (GREEN)
LED INDICATORS
LED INDICATORS
U22
PAL
(v1.x firmware cards only)
