Inter-Tel AXXESS - Figure 3-75 Example of a Multi-Site Setup Using PRI and BRI

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-142
Example of a Multi-Site Setup Using PRI and BRI
Figure 3-75. Example of a Multi-Site Setup Using PRI and BRI
PRI 30B+D TRUNK
New York
Miami
Phoenix
Los Angeles
ISDN
BRI Circuit
2B+D
BRI Circuit
2B+D
BRI Circuit
2B+D
3 BRS
Station/Station Ports
Connected to the ISDN Device
DEVICE
ISDN
DEVICE
ISDN
DEVICE
ISDN
DEVICE
