Inter-Tel AXXESS - Figure 3-43 New-Style Equipment Chassis Backplane

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-86
New-Style Equipment Chassis Backplane
Figure 3-43. New-Style Equipment Chassis Backplane
STATION AND TRUNK
CARD CONNECTORS
CPU CARD
CONNECTOR
EXPANDED CHASSIS
CONNECTOR
EXPANDED CHASSIS
CONNECTOR
(also used for the T1 Network
Clock Card, if needed)
POWER SUPPLY
CONNECTOR
NOT CURRENTLY
USED
NOT CURRENTLY
USED
J9
RN2
J10
RN5
