Inter-Tel AXXESS - Figure 3-20 DKSC Block Cable Terminations for Phones (U.S.)

Page 3-45
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
DKSC Block Cable Terminations for Phones (U.S.)
INSTALLATION
3
Figure 3-20. DKSC Block Cable Terminations for Phones (U.S.)
60M1-50-TYPE
BLOCK
(PART OF MDF)
AMPHENOL-
TYPE
CONNECTOR
DIGITAL
KEYSET
CARD
MODULAR
JACK
ASSEMBLY
DKSC
1.1.1
1.2.1
1.1.1
1.2.1
W/BL
BL/W
W/O
O/W
R/G
G/R
BR/V
S/V
TIP
RING
TIP
RING
TIP
DO NOT USE
DO NOT USE
G
R
Y
BK
TO DIGITAL
PHONE OR
SINGLE-LINE
ADAPTER
TO DIGITAL
PHONE OR
SINGLE-LINE
ADAPTER
DO NOT USE
DO NOT USE
RING
TIP
1.8.1
1.8.1
TIP
RING
G
R
Y
BK
V/S
