Inter-Tel AXXESS - Figure 5-11 Trunk DB Programming Flowchart

Page 5-295
System Features
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Trunk DB Programming Flowchart
FEATURES
5
Figure 5-11. Trunk DB Programming Flowchart
Enter Program Database
feature code 9932/9132
Press 3 or TRUNK menu button
ENTER DATABASE OPTION
ENTER TRUNK OPTION
Press 1 or INDIVIDUAL TRUNK
ENTER TRUNK EXTENSION
YOUR INPUT
PHONE DISPLAYS
AT ANY LEVEL:
Press * or the Speaker but-
ton to cancel any unsaved
changes and back up to
exit programming.
Press # or ACCEPT to
save changes and back up
one display level.
INFORMATION IN THIS
CHART IS SHOWN AS
FOLLOWS:
menu button
Press 2 or TRUNK GROUP
ENTER TRUNK GRP EXTENSION
menu button
SEE NEXT PAGE
Enter desired trunk
extension number
ANS SUPERVISION OPTION
Press 1 or POLARITY
REVERSE menu button
Press 2 or VALID
CALL menu button
SET Caller ID [CLIP]
Press 1 or ON
menu button
Press 2 or OFF
menu button
HYBRID BALANCE OPTION
Press 1 or NORMAL
menu button
Press 2 or SHORT
menu button
ENTER SIGNALING OPTION
Press 1 or DTMF
menu button
Press 2 or PULSE
menu button
ENTER TRUNK GRP EXTENSION
MARK TRUNK BUSY
Press 1 or
ANSWER SUPERVISION
menu button
Press 2 or
CALLER ID
menu button
Press 3 or
HYBRID BALANCE
menu button
Press 4 or
SIGNALING
menu button
TRUNK GROUP
menu button
INDIVIDUAL TRUNK OPTION
Press 6 or
TRUNK BUSY
menu button
Enter the trunk group number
Press 1 or ON
menu button
Press 2 or OFF
menu button
Press 5 or
Press 3 or VALID +
POLARITY menu button
