Inter-Tel AXXESS - Figure 3-100 Original Optional Fax Card

Page 3-221
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Original Optional Fax Card
INSTALLATION
3
Figure 3-100. Original Optional Fax Card
JUMPER
STRAP
SWITCHES
40-PIN CONNECTOR
TO AUDIO INTERFACE CARD
PIN 1
SW1
J503 (2, 4, 8-port)
J902 (12-port)
J2502 (16-port)
SW2 (2, 4, 8-port)
SW1001 (12-port)
SW2601 (16-port)
SW1 (2, 4, 8, 12-port)
SW2501 (16-port)
SW2
J503
SW1
