Inter-Tel AXXESS - Figure 2-13 Standard Display Phone

Page 2-110
Specifications
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Standard Display Phone
Figure 2-13. Standard Display Phone
LCD WITH TWO
16-CHARACTER LINES
HEARING AID-COMPATIBLE
(HAC) HANDSET
FEATURE
BUTTONS
12-KEY
KEYPAD
HANDSFREE
MICROPHONE
RING AND VOICE
VOLUME
CONTROLS
INTERNAL
SPEAKER
FEATURE
BUTTONS
SPECIAL
BUTTON
(underneath edge)
SPKR MSG
MUTE
FWD
∞
CALL 1
CALL 2
CALL 3
CALL 4
IC
DND
CNF
ANSWER
OUTGOING
HOLD
SYS SPDL REDIAL
TRANSFER
12 3
45 6
78 9
0
#
DEF
PRS TUV WXY
ABC
MNO
JKL
GHI
*
OPER
NOTE: The buttons are shown as they appear in the default keymap configuration.
PUSHBUTTON
