Inter-Tel AXXESS - Figure 3-81 OPC

Page 3-155
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
OPC
INSTALLATION
3
Figure 3-81. OPC
LED INDICATORS
SPECIAL
SOFTWARE
COMPONENTS
v1.x = 827.8038
v2.x - v8.0 = 827.8983
U3
NOTE: For purposes of detail, this drawing does not show the EMI shield attached to the front edge of the card.
U7
U8
CARD ON-LINE (GREEN)
CIRCUIT BUSY (YELLOW)
DSP PAL
RELAY
CONNECTOR
LOGIC INPUTS
CONNECTOR
DB15 PCM
CONNECTOR
RS232
CONNECTOR
MUSIC
CONNECTOR
(RESERVED FOR
FUTURE USE)
TO VOICE PROCESSING PC
AUDIO INTERFACE CARD (AIC)
v1.x = 827.8037
2.x - v8.0 = 827.8626
OPTIONAL DIGITAL
SIGNAL PROCESSORS
U29
U22
U5
U6
v8.1+ = 827.9950
v8.1+ = 827.9949
