Page 2-4
Specifications
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Introduction
1. INTRODUCTION
1.1 This section of the manual describes the following Inter-Tel
®
system hardware:
— Cabling and Main Distribution Frame (MDF)
—ATM Switch
— Chassis
— Power Supply Unit
— Circuit Cards
— Station Instruments
— Additional System Equipment
1.2 The trunks and stations are controlled by the circuit cards in the chassis. A single-chas-
sis system has seven slots available for station, trunk, and optional resource cards. A dual-chas-
sis system has up to 14 slots, a tri-chassis system has up to 21 slots, and a quad-chassis system
has up to 28 slots. An eight-chassis ATM-based system has up to 56 slots.
1.3 The maximum number of stations and trunks that can be installed depends on the num-
ber and type of cards and station instruments used. In most circumstances, the theoretical max-
imums listed in this manual are never reached due to the variety of cards and station
instruments installed.
1.4 A variety of “digital” station instruments can be used on the phone system, including:
• Axxess
®
Basic Digital Phones
• Eclipse™ Basic Digital Phones
• Standard Display Phones
• Associate Display Phones
• Executive Display Phones
• Professional Display Phones
• Model 8500, 8520, and 8560 Phones
NOTE: There are certain limitations associated with the Model 8500, 8520, and 8560
Phones when used with versions 3.0-6.x system software. See page 5-135 for details.
ALSO: The Professional Display, Associate Display, and Eclipse Basic Digital Phones
are supported by U.S. software only.
• 50- or 60-key Digital Direct Station Selection/Busy Lamp Field (DSS/BLF) Units
• 16-key Mini-DSS Units
NOTE: Version 7.0 or later software is required to support the Mini-DSS Units.
