Inter-Tel AXXESS - Figure 3-62 T1;E1;PRI Card

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-128
T1/E1/PRI Card
Figure 3-62. T1/E1/PRI Card
GAIN CONTROL DIP SWITCHES
LED INDICATORS
MAKE-BUSY
SERIAL PORT
T1/PRI SPAN
BANTAM TEST
T1/PRI SPAN DB15
CONNECTOR
WRITE-PROTECT
PRI PAL
J14
U14
SWITCH
JACK
JACK
JACK
NOTE: For purposes of detail, this drawing does not
show the EMI shield attached to the front edge of the
card.
CARD ON-LINE (GREEN)
CIRCUIT BUSY (YELLOW)
RED ALARM (RED)
YELLOW ALARM (YELLOW)
BLUE ALARM (YELLOW)
REFERENCE CLOCK (GREEN)
MAKE BUSY (YELLOW)
CARD HALTED (RED)
JUMPER
