Inter-Tel AXXESS - Figure 3-59 LGC and Optional LGC-D

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-122
LGC and Optional LGC-D
Figure 3-59. LGC and Optional LGC-D
LED INDICATORS
AMPHENOL-TYPE
CONNECTOR
NOTE: For purposes of detail, this drawing does not show the EMI shield attached to the front edge of the card.
CIRCUIT BUSY (YELLOW)
CARD ON-LINE (GREEN)
LGC
DAUGHTER CARD
