Inter-Tel AXXESS - Figure 3-11 LSC Block Cable Terminations (Europe Only)

Page 3-29
Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
LSC Block Cable Terminations (Europe Only)
INSTALLATION
3
Figure 3-11. LSC Block Cable Terminations (Europe Only)
NOTE: Circuits 1-4 (06.01.01-06.04.01) above are used by the LSC itself. If a Daughter Card is
attached, it uses circuits 5-8 (06.05.01-06.08.01).
FEMALE AMPHENOL-TYPE CONNECTORS
CABLE TO
MDF
1
26
W/BL-GR/R
TRUNKS
1-8
12
34
5
6
78
90
TRUNKS 1-8
Use non-conducting,
plastic connector covers
10 PAIR
TO LSC
TO
NETWORK
PROVIDER
