Installation

INTER-TEL

AXXESS

MANUAL VERSION 11.0 – May 2008

Page

3-114

AKSC/EKSC

Figure 3-56. AKSC/EKSC

LED INDICATORS

AMPHENOL-TYPE

CONNECTOR

CARD ON-LINE (GREEN)

CIRCUIT BUSY (YELLOW)

NOTE: For purposes of detail, this drawing does not show the EMI shield attached to the front edge of the card.
