Inter-Tel AXXESS - Figure 3-97 Audio Interface Card (AIC)

Installation
INTER-TEL
®
AXXESS
®
MANUAL VERSION 11.0 – May 2008
Page
3-218
Audio Interface Card (AIC)
Figure 3-97. Audio Interface Card (AIC)
2-PIN CONNECTOR
TO RESET SWITCH
2-PIN CONNECTOR
TO RESET CONNECTOR
ON MOTHERBOARD
40-PIN CONNECTOR
TO VOICE PROCESSING CARD(S)
JUMPER STRAPS
DIP SWITCHES
DB15F PCM CONNECTOR
TO CPU CARD
DB15F PCM CONNECTOR
TO OPTIONS CARD
PIN 1
J1
J2
J3
J4
J5
J6
J7
J8
S1
JUMPER STRAP
PIN 1
JUMPER STRAP
DIP SWITCH
