Page 3-199

Installation

INTER-TEL

AXXESS

MANUAL VERSION 11.0 – May 2008

Model 8520 or 8560 Phone PC Data Port Module (PCDPM) Installation

INSTALLATION

Figure 3-89. Model 8520 or 8560 Phone PC Data Port Module (PCDPM) Installation

PCDPM

ACCESS

PANEL

SCREW

MODEL 8560 PHONE

(BACK)

J10 PIN CONNECTOR

J3 CONNECTOR

(BACK)

CABLE SLOTS
